Halco - 14FSEPL/8DU - LED Select Edgelit Flat Panel 1x4 Watt & CCT Selectable Dimm
ProLED Select Edgelit Flat Panel 1x4 Wattage and Color Selectable 0-10V Dimmable 120-277V
Halco's ProLED Select Edgelit Panel is the ideal solution where lighting preferences vary from space to space. The Edgelit Panel Series is Field Selectable, allowing the installer to select both the preferred light output and color temperature (via DIP Switch) on the product driver box. The benefit of this is that one luminaire can replace 9 SKUs of our regular Edgelit Panels. Fewer luminaires mean less inventory and more efficient job site. At Halco, we only use the highest quality material in our Edgelit Panel Series design, eliminating the need to worry about yellowing, glare, or drooping after the product is installed. When applications like Healthcare facilities call for multiple lumen packages and color temperatures, the ProLED Select Edgelit Panel Series is the ideal solution to simplify BOMs and increase customer satisfaction.
Features
- Selectable Color Temperature: 3500K, 4000K, 5000K
- Selectable Light Output via Driver DIP Switch
- 0-10V Dimming Standard
- Emergency Back-Up Options
- 5-Year Warranty
- Low Glare Rating
Product Details
| Product Code | 14FSEPL/8DU |
| Halco Product ID | 10330 |
| UPC | 807154103300 |
| Category | Flat Panels |
| Technology | LED |
| Applications | C&I, E-Commerce, Distribution Commercial, Industrial, Retail, Storage, Utility, Shopping Centers, Task Lighting |
| Color Temperature | Selectable 3500K, 4000K or 5000K |
| Wattage | Selectable 25W, 30W or 40W |
| Lumens | 2750-4400 |
| Voltage | 120-277V |
| Dimmable | Yes (0-10V) |
| Finish | White |
| Location Rating | Damp |
| Warranty | 5 years |
| CRI | 80 |
| DLC | DLC 5.1 Standard |
| Energy Star | No |
| UL Listed | No |
| ETL Listed | Yes |
| IP Rating | IP40 |
| Title 24 | No |
| Dimensions L | 48.94 |
| Dimensions W | 2.48 |
| Dimensions H | 13.62 |
| Weight (lb) | 9.01 |
| Country of Origin | VN |
