Input Amps: 18 ~ 41mA
Dimensions: 15 1/2" x 11 1/4"
Certifications: UL listed for damp locations. (20°C – 50°C). Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA,
Local and State Codes
Warranty: 5 years warranty.
Charge rate/power “ON” LED indicator light and push-to-test switch for mandated code compliance testing.
4.8V long-life, maintenance-free, rechargeable NiCd battery.
Internal solid-state transfer switch automatically connects the internal battery to LED board for minimum 90-minute emergency illumination.
Fully automatic solid-state, two-rate charger initiates battery
charging to recharge a discharged battery in 24 hours.
Housing & Mounting:
Aluminum mounting canopy included for top or end mount.
Universal K/O pattern on back plate for wall mount.
Premium-grade, aluminum housing.
Field selectable knockout Chevron directional indicators.
Unique design allows double face conversion in the field.
Quick-snap face plate closure.
